KE-LED-EX 4003 tube luminaire 3x POWER LED | IP68 | Length 300mm
KE-LED-EX 4003 EX LED tube luminaire | IP68
The extremely compact ATEX LED tube light with explosion protection is the perfect solution for illuminating confined areas, containers and machines where reliable and modern lighting is of great importance. In addition, it meets all safety requirements with regard to explosion protection. With its three integrated POWER LED modules, it ensures optimal lighting and a clear view. The mounting brackets included in the scope of delivery enable quick and uncomplicated assembly. This luminaire offers you a compact and safe lighting solution for demanding environments where lack of space and explosion protection are of great importance.
Features
- ex-proof tube luminaire with 3 POWER LEDs / 6500 K
- Protection tube: polycarbonate, shock-resistant, 40 mm Ø
- End cap: aluminium, black anodized
- Fixation: incl. 2 fixing clamps made of plastic
- Protection category: IP68 - 50 m/5h (dust- and waterproof)
- Protection class: II / III
- Cable standard version: 10 m H07BQ-F 2 x 1,5 mm² (extendable in 5 m steps)
- Standard version without plug, Ex plug (ATX, CEAG) available on request
- Available in the voltage versions: 230V / 110V / 42V / 24V / 12V
- suitable for EX zones 1, 2, 21, 22 / ATEX certification
- Special requests - as covered by our Ex-certificaton - can be fulfilled
KIRA explosion proof LED hand lamps (leadlamps) for safe use in the areas: Sewage treatment plants, sewer inspection, electricity providers, mills, biogas plants, gas stations, tank automotive, aerospace industry, aircraft maintenance & inspection, oil rigs, offshore, shipyards, THW, EX-zones, explosive dust and gas atmospheres, gas interference, crafts, food industry, chemical industry, petrochemical industry.V
| Nominal voltage | 230V | 110V | 42V | 24V | 12V |
| AC | AC/DC | AC/DC | AC/DC | AC/DC | |
| Current | 0,03 A | 0,025 A | 0,075 A | 0,10 A | 0,20 A |
| Power | 3,3 W | 3,0 W | 3,8 W | 3,0 W | 2,8 W |
| Protection class | II | II | II | III | III |
| Real lumen | 200 Lm | 185 Lm | 180 Lm | 255 Lm | 235 Lm |
| Energy efficiency |  |
|
|
|
|
| Zones | 1, 2, 21, 22 | ||||
| Explosion protection gas |  II 2 G Ex eb mb op is IIC T4 Gb |
||||
| Explosion protection dust | II 2 G Ex eb mb op is IIC T4 Gb |
||||
| Number LED | 3 | ||||
| Color temperature | 6500 K | ||||
| CRI | > 70 | ||||
| Lifetime LED | > 50.000 h | ||||
| Tamb | -20 °C to +50 °C | ||||
| IP protection | IP68 | ||||
| Diffuser film | no | ||||
| Protective tube | polycarbonate | ||||
| End caps | aluminium, anodized | ||||
| Mounting bracket | 2x plastic brackets | ||||
| Cable | H07BQ-F | ||||
| Plug | without | ||||
| Weight | ca. 1,55 kg | ||||
| Length | ca. 320 mm | ||||
| KE-LED-EX 4003 tube luminaire / Dimensions mm | |||||||
| a | b | c | d | e | f | g | h |
| 35 | 100 | 120 | 45 | 20 | 43 | 40 | 300 |
2x Befestigungsklammer im Lieferumfang enthalten
| Mounting bracket BFK-D40 EX | ||||
| a | b | c | d | e |
| 67 | 25 | 20 | 40,4 | 58 |
| Number of mounting holes (f): 1x | ||||
Article overview KE-LED-EX 4003 / ATEX tube lumniaire
| Art-Nr. | 230V | Length of the supply line |
| 147101 | 220-240 Volt AC | 5 m H07BQ-F 2 x 1,5 mm² w/o plug |
| 147100 | 220-240 Volt AC | 10 m H07BQ-F 2 x 1,5 mm² w/o plug |
| 147102 | 220-240 Volt AC | 15 m H07BQ-F 2 x 1,5 mm² w/o plug |
| 147113 | 220-240 Volt AC | 20 m H07BQ-F 2 x 1,5 mm² w/o plug |
| Art-Nr. | 110V | Length of the supply line |
| 147109 | 110 Volt AC/DC | 5 m H07BQ-F 2 x 1,5 mm² w/o plug |
| 147110 | 110 Volt AC/DC | 10 m H07BQ-F 2 x 1,5 mm² w/o plug |
| 147111 | 110 Volt AC/DC | 15 m H07BQ-F 2 x 1,5 mm² w/o plug |
| 147112 | 110 Volt AC/DC | 20 m H07BQ-F 2 x 1,5 mm² w/o plug |
| Art-Nr. | 42V | Length of the supply line |
| 147119 | 42 Volt AC/DC | 5 m H07BQ-F 2 x 1,5 mm² w/o plug |
| 147120 | 42 Volt AC/DC | 10 m H07BQ-F 2 x 1,5 mm² w/o plug |
| 147121 | 42 Volt AC/DC | 15 m H07BQ-F 2 x 1,5 mm² w/o plug |
| 147122 | 42 Volt AC/DC | 20 m H07BQ-F 2 x 1,5 mm² w/o plug |
| Art-Nr. | 24V | Length of the supply line |
| 147134 | 24 Volt AC/DC | 5 m H07BQ-F 2 x 1,5 mm² w/o plug |
| 147130 | 24 Volt AC/DC | 10 m H07BQ-F 2 x 1,5 mm² w/o plug |
| 147137 | 24 Volt AC/DC | 15 m H07BQ-F 2 x 1,5 mm² w/o plug |
| 147138 | 24 Volt AC/DC | 20 m H07BQ-F 2 x 1,5 mm² w/o plug |
| Art-Nr. | 12V | Length of the supply line |
| 147143 | 12 Volt AC/DC | 5 m H07BQ-F 2 x 1,5 mm² w/o plug |
| 147140 | 12 Volt AC/DC | 10 m H07BQ-F 2 x 1,5 mm² w/o plug |
| 147144 | 12 Volt AC/DC | 15 m H07BQ-F 2 x 1,5 mm² w/o plug |
| 147145 | 12 Volt AC/DC | 20 m H07BQ-F 2 x 1,5 mm² w/o plug |
- Datasheet KE-LED-EX 4003 tube light (782.45 KB)
- ATEX certificate KE-LED-EX 3010 (599.61 KB)
- Tender text KE-LED-EX 4003 (563.4 KB)
- Safety instructions (563.81 KB)
